SULIN HIGH BAY – PRO SERIES

Warranty:

High Bay

Brief description:

The Sulin PRO high bay luminaire is an ideal choice for lighting large indoor environments such as halls, sports complexes, and industrial warehouses.

Features:

LM-80 certified to ensure the quality and longevity of the light source
(THD<15%) to reduce electrical noise
Wide input voltage range (100~265 VAC)
High power factor (PF>0.97) for greater energy efficiency
High optical efficiency, with an output of 150Lm/W

The Sulin PRO high bay luminaire is an ideal choice for lighting large indoor environments such as halls, sports complexes, and industrial warehouses.

Color rendering index (Ra) 80
Color temperature (K) 5000
Light source SMD LED
Lumen maintenance code 9
Luminous efficacy (Lm/W) 150
Light distribution angle (O)

Input voltage range (VAC) 100-265
Rated input voltage (VAC) 230
frequency (Hz) 50-60
LED Module Voltage
Power (W) 100 , 150 , 200
Power factor ≥ 0.95
Harmonic (%) ≤ 15%
Electric shock protection class I

Total weight (Kg) 100W=1.1
150W=1.5
200W=1.9
Overall dimensions (mm) 100W= Ø231 x H84
150W== Ø282 x H89
200W== Ø325 x H92
Body cover Electrostatic powder coating
Body material Diecast aluminum (ADC12)
Diffuser Material Tempered glass
Ingress Protection Rating (IP) 65
Pipe Holder Diameter (mm)
Impact protection rating (IK) 08
RAL color (RAL) 9005
Pipe Holder angles

Additional information

Application	Indoor hall lighting, industrial shed lighting, indoor stadium lighting
Permissible operating temperature (C°)	-20~+50
Warranty (years)	5
Maximum permissible humidity (%)	95
Nominal Lifespan (L70B10)	50000
